  • Hardware
    Network standards

    IEEE 802.3
    IEEE 802.3u
    IEEE 802.3x
    IEEE 802.3ab

    LED Indicator

    1* Power, 5* Link/Act

    Interfaces

    5*10/100/1000 Base-T Ethernet ports (Auto MDI/MDIX)

    Transmission media

    Recommended: CAT5/5e UTP or better

    Dimension

    82mm*52mm*22mm

    Material

    Plastic

    Level of protection

    ESD:
    Air discharge: ±8kV
    Contact discharge: ±6kV

    Forwarding mode

    Store-and-forward

    Switch capacity

    10Gbps

    Packet forwarding rate

    7.44Mpps

    Buffer

    1Mb

    MAC address table

    2K

    Power

    Input: 100-240V AC 50/60Hz
    Output: 5.0V 0.6A ( External Power Adapter )

    Power consumption

    Max:<3W

    Mounting

    Desktop mounting: support
    Wall mounting: support

    Environment

    Operating temperature: 0°C - 45℃
    Storage temperature: -40°C - 70°C
    Operating humidity: (10% - 90%)
    RH, non-condensing
    Storage humidity: (5% - 90%)
    RH, non-condensing

    Certification

    FCC, CE, RoHS

  • Software
    Protocols

    CDMA/CD

    MAC address learning

    Auto-Learning and Auto-Aging

    Funtions

    plug-and-play
