  • Hardware
    Standard&Protocol

    IEEE802.11a/b/g/n/ac/ax
    IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

    Ethernet Interface

    3 x 10/100/1000Mbps RJ45 ports per node

    Antenna

    7 x Built-in Antennas

    Button

    1 x Reset Button，1 x MESH Button

    Power

    Input: AC 100-240V~50/60Hz
    Output:DC 12V⎓2.5A

    Dimension

    105x105x220mm (4.13 x4.13 x 8.66 in)

    LED Indicator

    1 x LED

    Standard&Protocol

    IEEE802.3, IEEE802.3u,IEEE802.3ab

    Interfaces

    3 x 10/100/1000Mbps Wan/Lan Ports

    Antenna

    7* Built-in Antennas

    Button

    Reset Button*1
    MESH Button*1

    Power

    Input: AC 100-240V~50/60Hz
    Output:DC 12V 2.5A

    LED Indicator

    SYS*1

    Dimension

    4.13 x4.13 x 8.66 in(105x105x220mm)

  • Wireless
    Wireless Standard

    6GHz: IEEE 802.11ax
    5GHz: IEEE 802.11ax/ac/n/a
    2.4GHz: IEEE 802.11ax/n/b/g

    Wireless roaming

    Comply with IEEE802.11k/v/r

    Rate

    6GHz: 2402Mbps (802.11ax, HE160)
    5GHz: 2402Mbps (802.11ax, HE160)
    2.4GHz: 861Mbps (802.11ax)

    Frequency

    CE:
    2.4G: 2412-2472MHz(CH1-CH13)
    5G: 5150-5350MHz(CH36-CH64)
    6G: 5945-6425MHz(CH1-CH93)
    FCC:
    2.4G: 2412-2462MHz(CH1-CH11)
    5G: 5150-5350MHz(CH36-CH64)
    5725-5850MHz(CH149-CH165)
    6G: 5925-7125MHz(CH1-CH233)

    Transmission Power

    CE:
    <20dBm(2.4G)
    <23dBm(5G)
    <23dBm(6G)

    Basic Features

    MU-MIMO
    OFDMA
    1024-QAM
    Beamforming
    AP Steering
    Band Steering

    Wireless Security

    WPA2-PSK
    WPA3-SAE/WAP2-PSK

    Wireless Standard

    IEEE 802.11ax 6GHz
    IEEE 802.11ax/ac/n/a 5GHz
    IEEE 802.11ax/n/b/g 2.4GHz

    Data Rate

    6GHz: 2402Mbps
    5GHz: 2402Mbps
    2.4GHz: 861Mbps

    Frequency

    2.4GHz & 5GHz & 6GHz

    Transmission Power

    CE:
    <20dBm(2.4G)
    <23dBm(5G)
    <23dBm(6G)

    Basic Features

    MU-MIMO
    OFDMA
    1024-QAM
    Beamforming
    AP Steering
    Band Steering

    Wireless Security

    WPA2-PSK
    WPA3-SAE/WAP2-PSK

  • Software
    Operating Mode

    Wireless Router Mode
    AP Mode

    Internet Connection Type

    PPPoE, Dynamic IP, Static IP，PPPoE(Russia), PPTP(Russia), L2TP(Russia)

    DHCP Server

    DHCP Server
    DHCP Client List

    Virtual Server

    Port Forwarding, UPnP

    Parental Control

    Client Filter

    Firewall

    CMP Flood Attack Defense
    TCP Flood Attack Defense
    UDP Flood Attack Defense
    Ignore Ping Packet From WAN Port

    VPN

    PPTP/L2TP/IPsec Pass Through

    DNS

    Support DynDNS, No-ip

    Special Features

    Speed Test
    Monthly Report

    Others

    IPTV
    IPv6
    Tri Frequency In One
    Bandwidth Control
    Guest Network
    Static Routing
    System Log
    Remote Web Management
    MAC Clone
    Backup & Restore Configurations
    Support Automatic Access Detection
    Firmware Upgrade Online

    Internet Connection Type

    PPPoE, Dynamic IP, Static IP，PPPoE(Russia), PPTP(Russia), L2TP(Russia)

    Operating Mode

    Wireless Router Mode
    AP Mode

    DHCP

    DHCP Server
    DHCP Client List

    Virtual Server

    Port Forwarding,UPnP

    Firewall

    ICMP Flood Attack Defense
    TCP Flood Attack Defense
    UDP Flood Attack Defense
    Ignore Ping Packet From WAN Port

    DDNS

    DynDNS, No-ip

    VPN

    PPTP server
    PPTP client
    L2TP client

    Special Features

    Speed Test
    Monthly Report
    Tenda App

    Other Function

    IPTV
    IPv6
    Bandwidth Control
    Guest Network
    Static Routing
    System Log
    MAC Clone
    Remote Web Management
    Backup & Restore Configurations
    Support Automatic Access Detection
    Firmware Upgrade Online

  • Others
    Operation Temperature

    0 ~ 40 ℃

    Storage Temperature

    -40 ~ 70 ℃

    Operating Humidity

    10%~90% RH non-condensing

    Storage Humidity

    5%~90% RH non-condensing

    APP installation

    Available in iOS 8.0 or later, Android 4.0 or later

    Certification

    CE
    RoHS
    FCC

    Package Contents

    Mesh21XEP x 1, 12/2.5A Power adapter x 1, QIG x 1, RJ45 Gigabit Ethernet cable x 1

    Temperature

    Operating Temperature:0℃ ~ 40℃
    Storage Temperature : -40C ~70℃

    Humidity

    Operating Humidity : 10 %~90% RH non-condensing
    Storage Humidity : 5 %~ 90%RH non-condensing

    Certification

    CE/FCC/RoHS

    Package Contents

    Mesh21XEP*1
    Quick installation guide*1
    Gigabit Ethernet cable*1
    12V/2.5 A power adapter*3
