  • Hardware
    Standard&Protocol

    IEEE 802.3, IEEE 802.3u, IEEE 802.4ab

    Ethernet Interface

    2 x 10/100/1000Mbps RJ45 ports per node

    Antenna

    2 x Internal antenna

    Button

    1 x Reset Button

    Power

    Input: 100-240V—50/60Hz, 0.6A
    Output: 12V1A

    Dimension

    91 x 91 x 93mm (3.58 x 3.58 x 3.66 in.)

    LED Indicator

    1 x Tri-color LED
    Indicator(Green,Yellow,Red)

  • Wireless
    Wireless Standard

    IEEE802.11a/b/g/n/ac (WiFi 5 wave 2)

    Wireless roaming

    Comply with IEEE802.11k/v/r

    Mesh network Standard

    IEEE802.11s

    Rate

    2.4GHz: 300Mbps
    5GHz: 867Mbps

    Frequency

    2.4~2.4835GHz
    5.15~5.25GHz
    5.725~5.85GHz

    Transmission Power

    CE:
    <20dBm(2.4G)
    <23dBm(5G)

    Basic Features

    SSID Broadcast
    Beam Forming
    MU-MIMO
    AP Steering
    Band Steering

    Wireless Security

    WPA-PSK/WPA2-PSK(default)

  • Software
    Operating Mode

    Router Mode,Bridge Mode

    Internet Connection Type

    PPPoE, Dynamic IP, Static IP
    PPPoE(Russia), PPTP(Russia), L2TP(Russia)

    DHCP Server

    DHCP Server, DHCP Client List

    Virtual Server

    Port Forwarding, UPnP

    Parental Control

    Client Filter

    Firewall

    Forbid TCP/UDP flood attack

    VPN

    PPTP/L2TP/IPsec pass through

    DNS

    Support manually setting DNS server

    Special Features

    Smart QoS (Gaming, Video & Audio, Download)

    Others

    Auto-sensing internet connection
    Support App management and Remote management
    Guest Network
    Firmware upgrade online

  • Others
    Operation Temperature

    0 ~ 40 ℃

    Storage Temperature

    -40 ~ 70 ℃

    Operating Humidity

    10%~90% RH non-condensing

    Storage Humidity

    5%~90% RH non-condensing

    APP installation

    Available in iOS 8.0 or later, Android 4.0 or later

    Certification

    CE, FCC, RoHS,EAC,IC

    Package Contents

    Mesh5 x 3, Power adapter x 3, QIG x 1, RJ45 Gigabit Ethernet cable x 1
