IEEE802.11a/b/g/n/ac
IEEE 802.3, IEEE 802.3u, IEEE 802.4ab

Primary Node: 2 x 10/100/1000Mbps RJ45 ports
Secondary Node: 2 x 10/100Mbps RJ45 ports

2 x Internal antenna

1 x Reset Button

Primary Node Input: 100-240V—50/60Hz, 0.6A
Output: 12V1A
Secondary Node Input:100-240V—50/60Hz, 0.3A
Output: 9V 800mA

Primary Node: 91 x 91 x 93mm (3.58 x 3.58 x 3.66 in.)
Secondary Node: 114 x 68 x45mm (4.48 x 2.67 x 1.77 in.)

1 x Tri-color LED
Indicator(Green,Yellow,Red)

IEEE802.11a/b/g/n/ac (WiFi 5 wave 2)

Comply with IEEE802.11k/v/r

IEEE802.11s

2.4GHz: 300Mbps
5GHz: 867Mbps

2.4~2.4835GHz
5.15~5.25GHz
5.725~5.85GHz

CE:
<20dBm(2.4G)
<23dBm(5G)

SSID Broadcast
Beam Forming
MU-MIMO
AP Steering
Band Steering

WPA-PSK/WPA2-PSK(default)

Router Mode,Bridge Mode

PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)

DHCP Server, DHCP Client List

Port Forwarding, UPnP

Client Filter

Forbid TCP/UDP flood attack

PPTP/L2TP/IPsec pass through

Support manually setting DNS server

Smart QoS (Gaming, Video & Audio, Download)

Auto-sensing internet connection
Support App management and Remote management
Guest Network
Firmware upgrade online

0 ~ 40 ℃

-40 ~ 70 ℃

10%~90% RH non-condensing

5%~90% RH non-condensing

Available in iOS 8.0 or later, Android 4.0 or later

CE, FCC, RoHS,EAC,IC

Mesh5 x 1, Mesh5s x 2, Power adapter x 1, QIG x 1, RJ45 Gigabit Ethernet cable x 1
