IEEE 802, 802.1Q, 802.10, IEEE 802.11, 802.3U, 802.3Z

ITU G.984.1, ITU G984.2, ITU G984.3, ITU G984.4

1*SC/APC GPON Port, 1*1000Mbps RJ45 LAN Port, 3*100Mbps RJ45 LAN Ports, 1*USB Port, 1*VoIP Port, 1*DC Port

PWR, PON, LOS, LAN1, LAN2，LAN3, LAN4, TEL,WLAN, WPS, USB

1* Power On/Off Button, 1*WPS Button, 1*WLAN Button, 1 RESET Button ，1*LED Button

Class B+

Transmit at 1310nm, Receive at 1490nm

20km Max

Upstream 1.25Gbps Max, Downstream 2.5Gbps Max

20M/40M

163*115*28 mm (W * D * H)

0.5~5dBm

-28~-8dBm

DC 12V /1.0A

≤12w

Server, Client, DHCP Client List, Address Reservation, DHCP Relay

PPPoE , Dynamic IP, Static IP, Bridge

TR069, Internet, IPTV, VoIP

Bandwidth Control

IPv4, IPv6

DHCP, Dynamic DNS , IGMP Proxy UPnP, Samba

PPTP, L2TP, IPsec Pass-through

ALG, IP Filter ,Port Filter, Mac Filter, URL Filter Port Forwarding， DMZ

Radvd, DHCPv6, MLD Proxy, MLD Snooping

Ping, Ping6, Tracert, Tracert6

ACS, Connection request

Main Proxy, Black Proxy, SIP Advanced, Forward Mode, Speed Dial, Dial Plan , Codec, Hotline, DND, Alarm

2.4GHz，IEEE802.11 b/g/n

CH1-CH13

2 * 6 dBi Antenna

WPS Button, WPS LED

11n 300M

<20 dBm(EIRP)

Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics

64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK Encryption, Wireless MAC Filtering

Main SSID
4 Guest SSIDs

32

0°c ~ 45°c

-40°c ~ 70°c

10% ~ 90% （Non-condensing）

5% ~ 90% (Non-condensing)

1*HG6,1* Power adapter, 1* Quick install guide, 1* RJ45 cable, 1* RJ11 cable

CE, FCC, RoHS, Anatel
